The Warrior Cable® to 50 GHz

Rugged and Crush-Proof—When Downtime is Not an Option

  • Soldier Proof Solution
  • Stable Under Vibration and Abuse
  • Crush Resistant to 250 lbs/linear in (45 kg/linear cm)
  • Rugged GrooveTube® Technology
  • Proprietary Pull-Resistant Connector Design
  • Jacketed to withstand the elements, including chemicals.

The MegaPhase Warrior Cable® is a combat proven, “soldier proof” solution ideal for ground-based EW and ECM. This cable is internally armored with GrooveTube® Technology, a crush-proof outer conductor, surviving in the harshest conditions including salt, fog, humidity, dust, sand, vibration, and flexure.

Convoluted copper cable is innovated and manufactured at MegaPhase under a licensing agreement with Flexco Microwave, Inc.

Part Numbers

F520
REQUEST QUOTE PART NUMBERING VIEW DATA SHEET

Specifications –  Warrior Series



FREQUENCY

           ATTENUATION   VSWR Connector

Loss dB
GHz Band dB/ft dB/m
0.3

UHF

 0.062 0.203



1.10

 0.006
0.5 0.082 0.268 0.009
0.8 0.106 0.348 0.012
1.0 L 0.120 0.394 0.014
2.0

S

 0.178 0.585

1.15

 0.024
2.4 0.199 0.652 0.027
3.0 0.227 0.744 0.032
4.0

C

 0.270 0.885

1.20

 0.040
6.0 0.347 1.138 0.055
8.0

X

 0.417 1.367 0.070
10.0 0.482 1.580 1.25 0.084
12.4 0.555 1.822







1.30

 0.101
15.0

Ku

 0.631 2.070 0.118
18.0 0.715 2.345 0.139
20.0

K

 0.769 2.522 0.152
22.0 0.821 2.695 0.165
24.0 0.873 2.865 0.178
26.5 0.937 3.073





1.35

 0.194
28.0

Ka

 0.974 3.196 0.204
30.0 1.024 3.358 0.217
32.0 1.072 3.518 0.230
34.0 1.121 3.676

1.40

 0.243
36.0 1.168 3.833 0.256
40.0 1.262 4.141

1.45

 0.281
45.0 Q 1.377 4.518 0.313
50.0 V 1.490 4.888 1.50 0.344
